PVC FLEXIBLE CORD

PVC FLEXIBLE CORD
PVC FLEXIBLE CORD
AMERICA/CANADA STANDARD PVC FLEXIBLE CORD
STANDARD:UL 62 Flexible cord and fixture wire
CSA C22.2 No.49 Flexible Cord and Cables.

SPT-1/W、SPT-2/W、SPT-3、NISPT-1、NISPT-2(60℃/105℃ 300V)
CORD TYPES	SECTION	CONDUCTOR			Overall diameter	Rating(A)
CORD TYPES	SECTION	AWG	Area(mm²)	Ω/km(20℃)	Overall diameter	Rating(A)
SPT-1 SPT-1W		20×2	0.519	35.7	2.5×5.0	7
		18×2	0.824	22.4	2.7×5.4	10
		20×3	0.519	35.7	2.5×7.0	7
		18×3	0.824	22.4	2.8×7.5	10
SPT-2 SPT-2W		18×2	0.824	22.4	3.5×6.9	10
		16×2	1.31	14.1	3.8*7.5	13
		18×3	0.824	22.4	3.6×8.7	10
		16×3	1.31	14.1	3.8×9.5	13
SPT-3		18×2	0.824	22.4	4.2×8.4	10
		16×2	1.31	14.1	4.6×9.2	13
		14×2	2.08	8.88	5.8×10.6	15
		18×3	0.824	22.4	4.2×9.6	10
		16×3	1.31	14.1	4.6×11	13
		14×3	2.08	8.88	5.8×13.6	15
NISPT-1		20×2	0.519	35.7	2.7×4.8	7
		18×2	0.824	22.4	3.0×5.4	10
		20×3	0.519	35.7	2.7×6.8	7
		18×3	0.824	22.4	3.0×7.9	10
NISPT-2		18×2	0.824	22.4	3.7×7.0	10
		16×2	1.31	14.1	4.0×7.3	13
		18×3	0.824	22.4	3.7×10.2	10
		16×3	1.31	14.1	4.0×11	13
